novo.lign

  • Novo.lign Veneers

    Natural beauty
    natural designs and effect of depth – can be perfectly combined with neo.lign teeth
    Simple handling
    extended necks, can be thermoformed and individualised with crea.lign
    Reliability
    proven system – more than 10 million veneers inserted

    The novo.lign veneers consist of high impact polymer composite filled with microceramic, and can be used for the permanent veneering of metal, ceramic and polymer frameworks.

    They are moulded from real rows of teeth and, therefore, give a perfect natural look. The morphological layer structure also ensures the veneer has a natural depth.

    Thanks to its exceptional mechanical properties, such as its high flexural strength (140 MPa) and low modulus of elasticity (approx. 3,000 MPa), the physiological veneers have a shock-absorbing effect and are, therefore, perfect for implant prosthetics. The homogeneous and sealed surface ensures long-term colour stability and plaque resistance. Because they have the same shades and shapes, they can be seamlessly combined with neo.lign denture teeth.






    • Natural beauty

      • Natural design, because every novo.lign veneer is moulded from real rows of teeth
      • Natural depth effect thanks to the morphological layer structure
      • Same shades and shapes as the neo.lign denture teeth
      • Homogeneous and sealed surface ensures long-term colour stability and plaque resistance



    • Simple handling

      • Extended neck enabling individual setting of tooth length
      • Can be thermoformed, and therefore adapted to any situation
      • novo.lign veneers can be seamlessly combined with neo.lign denture teeth, and are therefore perfect for the combination technique and for implant prosthetics (same shades and shape)
      • Can be be individualised with crea.lign veneering composite







    • Reliability

      Veneer with a high load-bearing capacity

      Highly stable bond:
      The best bonds between novo.lign veneers and framework materials are achieved using the bond.lign primer/bonder (see the Voss shear test conducted by the University of Jena on page 12/13 of novo.lign brochure Ref.009939GB).
      High-strength, fracture-proof & abrasion-resistant:
      Thanks to its high impact polymer structure and high flexural strength of approx. 140 MPa, the novo.lign veneers are very strong and fracture-proof. The ceramic filler structure also increases its resistance to abrasion.
      No spalling or cracks thanks to the similar modulus of elasticity of the interacting novo.lign, BioHPP, combo.lign and crea.lign products.
      Proven system: More than 10 million veneers inserted

    • Intraoral application

      • Perfect for implant prosthetics
      novo.lign’s low modulus of elasticity (approx. 3,000 MPa) ensures that the implant has a shock-absorbing effect.
      The interaction of the similar moduli of elasticity of BioHPP (approx. 4,500 – 5,000 MPa), novo.lign (approx. 3,000 MPa), combo.lign (9,000 MPa) and crea.lign (5,000 MPa) also support the implant’s shock absorbing effect and make the whole restoration high physiological.
      • Natural feel in the mouth
      thanks to the neutral flavour and neutral behaviour in contact with cold and hot food. No chattering of teeth. Does not feel like a foreign object in the mouth.
      • Biocompatible
      Barely any residual monomer as the veneer is completely polymerised at 250 bar and 120 °C.
      • Protection of antagonists,
      as no dental glass is used in the material.

    • novo.lign A – 15 anterior shapes


        All available anterior shapes can be seen in “Range of designs” brochure


      Buccal wall thickness 1.0 mm
      • 12 upper moulds
      • 3 lower moulds

      Available shades


        Order form is available for download




    • novo.lign P
      G designs – 2 posterior shapes


        All available posterior shapes of G design can be seen in”Range of designs” brochure


      Buccal wall thickness 1.2 mm
      • Multi-functional occlusal design
      for all occlusion concepts

      Available in sizes



      Available shades


        Order form is available for download


      L designs – 2 posterior shapes


        All available posterior shapes of L design can be seen in “Range of designs” brochure


      Buccal wall thickness 1.0 mm
      • lingualised occlusal design for full dentures



      Available in sizes



      Available shades


        Order form is available for download


      W designs – 3 posterior shapes


        All available posterior shapes of W design can be seen in “Range of designs” brochure


      Buccal wall thickness 0.8 mm
      • Multi-functional occlusal design for all occlusion concepts
      • Extra-wide tooth design, particularly recommended for veneering crowns and bridges



      Available in sizes



      Available shades


        Order form is available for download


    • A&P sets

      novo.lign A&P sets content






    • Clearly legible display


      Bre.LUX Spacious Drawer

      Spacious drawer

      The focus in the development was on ease of use and a particularly large capacity. The drawer easily accommodates large-size objects, such as flasks.


      Bre.LUX Full Range Light

      Using the benefits of the entire relevant spectrum of light

      Experience a new level of reliability and speed when polymerizing your objects. The innovative and new LED technology of bre.Lux 2 covers the entire relevant spectrum of light below 400 nm and hence enables a new quality of polymerization. It offers the user more consistent and faster curing since different wavelengths can reach different depths. Increase your reliability and reduce your polymerization times.


      Bre.LUX Rotary Plate

      Rotary plate and Light-Tray

      Convenient, activatable, removable – this rotary plate guarantees that the object is evenly illuminated by the 72 LED lights from all sides. As a transparent tray, the Light-Tray transports light to areas that are otherwise inaccessible. Expose the objects to pure light!


      Outstanding power

      Outstanding power

      72 LED lamps will give you unsurpassed and highly efficient luminous power to prevent shrinkage in a clever way. Moreover, temperature control of 45°C – 55°C eliminates thermal influences such as overheating and embrittlement of the object. Additionally, the fan is extremely silent.


      12 years

      12 years (20,000 hours) at your service

      In a highly efficient manner, the 72 LED lights of bre.Lux 2 transform the power input into light energy and offer a longer service life than halogen lights (max. service life of 2,000 hours).

    • bre.LUX LED N2 hand lamp

      Bre.LUX LED N2 Hand Lamp





    • Thermo-Pen








      Hot air blower with piezo technique

      The Thermo-Pen works without an open flame and can feed hot air up to 250 °C into the veneer interior.

      Thermo-Pen
      Thermo Pen 2
    • ZTM Sebastian Schuldes M.Sc.

      The aesthetic fitting enables the patient to see the results in their mouth in advance. I think this is the most important advantage of veneers compared to other veneering materials. The aesthetic fitting helps me and the dentist advise patients, it is therefore a vital factor in our communication with our patients. The novo.lign veneers offer me a reproducible aesthetic. It doesn’t matter which member of the laboratory team processes the novo.lign veneers, I always get a top-quality aesthetic result. This gives me certainty and makes my laboratory even more efficient.

      Sebastian Schuldes, Dental Technician, M.Sc.
    • ZTM Antonio Lazetera

      I have been successfully working with novo.lign veneers and neo.lign denture teeth since 2007. The system consisting of novo.lign, the corresponding bonding composite and the corresponding primer/bonder doesn’t just help me achieve a high aesthetic level, it also ensures the long-term success of the restoration due to its high plaque-resistance and low staining susceptibility. For combination work and implant prosthetics, the combination of novo.lign and neo.lign is the perfect solution for me.

      Antonio Lazetera, Dental Technician
    • ZTM Sebastian Schuldes M.Sc.
    • ZTM Antonio Lazetera
  • visio.lign The Aesthetic and Functional System brochure

    REF 000224GB

    visio.lign Das Ästhetik und Funktionssystem

    REF 009939GB

    crea.lign Veneering composite brochure

    REF 000202GB

    visio ling Veneering system

    REF 009504GB

    visio.lign Manual Composite processing techniques

    REF 000234GB

  • visio.lign_order_form_EN
